Pixel Configuration
SMD Triad LED (with glue)
Pixel Pitch Category
P1.5
Pixel Pitch
1.5625 mm
Modules Component
1 × 1 ;
3 × 1 ;
2 × 2 ;
Dimensions (W × H × D)
250 mm × 250 mm × 40.6 mm (9.84" × 9.84" × 1.60");
750 mm × 250 mm × 40.6 mm (29.53" × 9.84" × 1.60");
500 mm × 500 mm × 40.6 mm (19.69" × 19.69" × 1.60");
Resolution
160 × 160 ;
480 × 160 ;
320 × 320 ;
0.35 kg (0.702 lb)
Pixel Density
409,600 dots/m²
Lamp Board Housing
With housing
Cabinet Material
Aluminium die casting
Maintenance Method
Front maintenance for all components
Cabinet Flatness
0.1 mm (0.00039")
Protection Level
Front protection level IP40
Applicable Cabinet Frame
DS-D40CE11-2F，DS-D40CE13-2F，DS-D40CE22-2F
